Bharat Wire provides advanced water management systems designed for modern infrastructure, highways, and civil structures.

The Future of Efficient Water Drainage

CHSL pipe stands for Corrugated High-Strength Lightweight Pipe, a next-generation drainage conduit engineered to offer superior flexibility, load-bearing capacity, and durability — all in a lightweight form. Manufactured from HDPE (High-Density Polyethylene), this corrugated plastic pipe is rapidly replacing traditional concrete and metal drainage systems due to its long service life, ease of handling, and resistance to corrosion.

From stormwater management and culvert installations to highway drainage and subsurface water diversion, CHSL pipes are becoming the preferred choice across India's infrastructure landscape. As a trusted CHSL pipe manufacturer, Bharat Wire delivers high-quality, technically compliant products tailored to modern drainage demands.

Widespread Civil Uses of CHSL Pipe Systems

Highway and Roadway Drainage

Installed beneath medians or roadside embankments to channel rainwater efficiently.

Stormwater Management Projects

Used in stormwater CHSL pipe networks for urban and industrial areas.

Culvert and Cross-Drain Installations

Ideal for culverts, replacing heavy concrete in bridges and underpasses.

Agricultural Drainage

Deployed in farmlands to manage excess water and prevent crop loss.

Railway Embankment Drainage

Maintains soil integrity under railbeds by draining excess moisture.

Industrial and Urban Water Diversion

Supports fluid flow in industrial zones and real estate developments.

The Advantage of Corrugated HDPE Pipes in Modern Infrastructure

Lightweight and Easy to Install

Reduces transport and installation costs with quicker deployment.

Corrosion and Chemical Resistance

HDPE resists rust, corrosion, and harsh chemicals in tough environments.

High Strength with Flexibility

Withstands loads while adapting to ground movement without cracking.

Long-Term Durability

Offers service life over 50 years with low maintenance requirements.

Efficient Flow Capacity

Smooth inner walls reduce friction and ensure efficient drainage flow.

Environmentally Friendly

Made from recyclable materials and supports sustainable development.

Versatile Application

Suited for highways, airports, agriculture, cities, and more.

Core Functional Strengths of CHSL Pipe Technology

Durable & Weather-Resistant

Made from UV-stabilised HDPE for long-term exposure. Withstands thermal expansion and environmental stress.

Lightweight & Easy to Handle

Up to 70% lighter than concrete or metal pipes. Enables faster laying and reduced transport costs.

High Structural Integrity

Engineered with dual-layer corrugated strength. Resists deformation from soil and vehicular load.

Versatile & Flexible

Adapts to curves, slopes, and site contours. Ideal for alignment adjustments in complex terrain.

Chemically & Biologically Inert

Impervious to rust, corrosion, and biological decay. Suitable for use in aggressive environments.

Technical Specifications at a Glance

Parameter Specification
Pipe Material High-Density Polyethylene (HDPE)
Pipe Type Double-wall corrugated with smooth inner bore
Available Diameters 100 mm to 1000 mm (custom sizes on request)
Length per Section 3 m, 6 m, or site-specific lengths
Connection Types Bell & Spigot / Coupler with Rubber Seals
Load Class Suitable for traffic load (AASHTO, IRC standards)
Standard Compliance IS 16098 Part 2 / ASTM F2648 / EN 13476
Installation Suitability Trenched, trenchless, culvert, and subsurface applications
Flow Efficiency Smooth inner wall with low Manning's roughness coefficient

Why Partner with Bharat Wire for CHSL Drainage Systems?

Proven Industry Experience
Custom Pipe Solutions
High Durability
Corrosion Resistance
Fast Delivery & Support
Eco-Friendly Manufacturing
Cost-Effective Options
Trusted by Leading Projects

FAQs

  • What is CHSL pipe used for in civil engineering?

    CHSL pipe is widely used in road drainage, culverts, stormwater systems, and subsurface water management for its flexibility, strength, and corrosion resistance.

  • How does CHSL pipe compare with concrete pipes?

    CHSL pipes are lighter, easier to install, corrosion-resistant, and offer longer life expectancy with less maintenance, especially in aggressive soil and water environments.

  • Is CHSL pipe suitable for culvert installation under highways?

    Yes, our CHSL pipe for culverts is designed to bear traffic loads, including HGVs, and complies with Indian Roads Congress (IRC) specifications.

  • How is CHSL pipe installed?

    Installation involves trench preparation, pipe laying with rubber-gasketed joints or couplers, backfilling, and compaction — all achievable with light machinery.

  • What is the cost of CHSL pipe per metre in bulk?

    Cost varies by diameter, wall thickness, coating, and quantity. Contact us for a bulk pricing estimate based on your project needs.

Get in Touch

Are you planning a drainage project, road development, or stormwater system installation? Choose Bharat Wire's CHSL Pipe for strength, speed, and sustainability
